Specifications

Actuator Length	17.50mm
Actuator Material	Brass, Nickel Plated
Actuator Type	Standard Round
Bushing Thread	M12 x 0.75
Circuit	DPDT
Current Rating (Amps)	10A (AC)
Electrical Life	6,000 Cycles
Features	-
Illumination	Non-Illuminated
Illumination Type, Color	-
Illumination Voltage (Nominal)	-
Ingress Protection	-
Mounting Type	Panel Mount
Operating Temperature	-20°C ~ 55°C
Package	Bulk
Panel Cutout Dimensions	Circular - 12.20mm Dia
Product Status	Active
Rohs Status	ROHS3 Compliant
Series	600H
Standard Package	25
Switch Function	On-Off-On
Termination Style	Quick Connect - 0.250" (6.3mm)
Voltage Rating - Ac	250V
Datasheet	649H/2
